SWE 90UF

The Sunward SWE 90UF compact excavator was launched at the end of 2020. The SWE 90UF has been developed especially for a European market, where contractors, from demolition to rental market, will appreciate a compact machine that delivers heavy-duty performance. It features a very short-tail swing, making it the shortest 9-ton short-tail excavator (by almost 20 cm) available in the market.

Emission rating: EU Stage V
Operating weight 8 750 – 8 900 kg
Power output 46.2 kW
Max. digging depth 4 545 mm
Width 2 250 mm



SUNWARD SWE 90UF

The Sunward SWE 90UF compact excavator was launched at the end of 2020. The SWE 90UF has been developed especially for a European market, where contractors, from demolition to rental market, will appreciate a compact machine that delivers heavy-duty performance. It features a very short-tail swing, making it the shortest 9-ton short-tail excavator (by almost 20 cm) available in the market. Thanks to its design, the SWE 90UF can offer great power at a reduced footprint, giving it the ability to fit into smaller spaces than other similar products.
It combines the power of the Yanmar 4TNV98C engine, delivering 46.2 kW, with incredible precision thanks to the dual proportional joysticks, the perfectly fitted hydraulic flow coupled with the LUDFF system (Load Independent Flow Control). To balance between fuel consumption and the desired productivity, the SWE 90UF offers 3 working modes.
Of course, because we know that safety and comfort should go hand-in-hand, the SWE 90UF keeps you safe and provides every comfort in all working conditions.
In the Sunward tradition to always offer the best value for money, the SWE 90UF is no exception since it offers many features and up to 5 years of warranty as standard, at the right price.
Discover all the other advantages of the Sunward SWE 90UF.

Operating weight 8 750– 8 900 kg
Standard bucket Capacity 0.26 m³
Shipping length 6 494 mm
Shipping width 2 250 mm
Height over cabin 2 735 mm
Model Yanmar 4TNV98C
Emission rating EU Stage V
Displacement 3.319 L
Rated power output 46.2 kW
Type 1 variable piston pump
Displacement 160 L/min
Hydraulic pressure 28 Mpa
Max. digging depth 4 545 mm
Max. digging reach 7 445 mm
Max. bucket digging force 63.5 kN
Max. arm digging force 38 kN
